β\beta-diversity measures how different local systems are from one another (Moreno and Rodríguez 2010).

## Install extra packages (if needed)
# install.packages("folio") # Datasets

## Load packages
library(tabula)

## Ceramic data from Lipo et al. 2015
data("mississippi", package = "folio")

Turnover

The following methods can be used to ascertain the degree of turnover in taxa composition along a gradient on qualitative (presence/absence) data. This assumes that the order of the matrix rows (from 1 to mm) follows the progression along the gradient/transect.

We denote the m×pm \times p incidence matrix by X=[xij]i[1,m],j[1,p]X = \left[ x_{ij} \right] ~\forall i \in \left[ 1,m \right], j \in \left[ 1,p \right] and the p×pp \times p corresponding co-occurrence matrix by Y=[yij]i,j[1,p]Y = \left[ y_{ij} \right] ~\forall i,j \in \left[ 1,p \right], with row and column sums:

xi=j=1pxijxj=i=1mxijx=j=1pi=1mxijxij{0,1}yi=jipyijyj=ijpyijy=i=1pjipyijyij{0,1}\begin{align} x_{i \cdot} = \sum_{j = 1}^{p} x_{ij} && x_{\cdot j} = \sum_{i = 1}^{m} x_{ij} && x_{\cdot \cdot} = \sum_{j = 1}^{p} \sum_{i = 1}^{m} x_{ij} && \forall x_{ij} \in \lbrace 0,1 \rbrace \\ y_{i \cdot} = \sum_{j \geqslant i}^{p} y_{ij} && y_{\cdot j} = \sum_{i \leqslant j}^{p} y_{ij} && y_{\cdot \cdot} = \sum_{i = 1}^{p} \sum_{j \geqslant i}^{p} y_{ij} && \forall y_{ij} \in \lbrace 0,1 \rbrace \end{align}

Turnover measures.
Measure Reference
βW=Sα1 \beta_W = \frac{S}{\alpha} - 1 Whittaker (1960)
βC=g(H)+l(H)21 \beta_C = \frac{g(H) + l(H)}{2} - 1 Cody (1975)
βR=S22y+S1 \beta_R = \frac{S^2}{2 y_{\cdot \cdot} + S} - 1 Routledge (1977)
βI=logxj=1pxjlogxjxi=1mxilogxix \beta_I = \log x_{\cdot \cdot} - \frac{\sum_{j = 1}^{p} x_{\cdot j} \log x_{\cdot j}}{x_{\cdot \cdot}} - \frac{\sum_{i = 1}^{m} x_{i \cdot} \log x_{i \cdot}}{x_{\cdot \cdot}} Routledge (1977)
βE=exp(βI)1 \beta_E = \exp(\beta_I) - 1 Routledge (1977)
βT=g(H)+l(H)2α \beta_T = \frac{g(H) + l(H)}{2\alpha} Wilson & Shmida (1984)

Where:

  • α\alpha is the mean sample diversity: α=xm\alpha = \frac{x_{\cdot \cdot}}{m},
  • g(H)g(H) is the number of taxa gained along the transect,
  • l(H)l(H) is the number of taxa lost along the transect.

Similarity

Similarity between two samples aa and bb or between two types xx and yy can be measured as follow.

These indices provide a scale of similarity from 00-11 where 11 is perfect similarity and 00 is no similarity, with the exception of the Brainerd-Robinson index which is scaled between 00 and 200200.

Qualitative similarity measures (between samples).
Measure Reference
CJ=ojSa+Sboj C_J = \frac{o_j}{S_a + S_b - o_j} Jaccard
CS=2×ojSa+Sb C_S = \frac{2 \times o_j}{S_a + S_b} Sorenson
Quantitative similarity measures (between samples).
Measure Reference
CBR=200j=1S|aj×100j=1Sajbj×100j=1Sbj| C_{BR} = 200 - \sum_{j = 1}^{S} \left| \frac{a_j \times 100}{\sum_{j = 1}^{S} a_j} - \frac{b_j \times 100}{\sum_{j = 1}^{S} b_j} \right| Brainerd (1951), Robinson (1951)
CN=2j=1Smin(aj,bj)Na+Nb C_N = \frac{2 \sum_{j = 1}^{S} \min(a_j, b_j)}{N_a + N_b} Bray & Curtis (1957), Sorenson
CMH=2j=1Saj×bj(j=1Saj2Na2+j=1Sbj2Nb2)×Na×Nb C_{MH} = \frac{2 \sum_{j = 1}^{S} a_j \times b_j}{(\frac{\sum_{j = 1}^{S} a_j^2}{N_a^2} + \frac{\sum_{j = 1}^{S} b_j^2}{N_b^2}) \times N_a \times N_b} Morisita-Horn
Quantitative similarity measures (between types).
Measure Reference
CBi=oiN×pN×p×(1p) C_{Bi} = \frac{o_i - N \times p}{\sqrt{N \times p \times (1 - p)}} Kintigh (2006)

Where:

  • SaS_a and SbS_b denote the total number of taxa observed in samples aa and bb, respectively,
  • NaN_a and NbN_b denote the total number of individuals in samples aa and bb, respectively,
  • aja_j and bjb_j denote the number of individuals in the jj-th type/taxon, j[1,S]j \in \left[ 1,S \right],
  • xix_i and yiy_i denote the number of individuals in the ii-th sample/case, i[1,m]i \in \left[ 1,m \right],
  • oio_i denotes the number of sample/case common to both type/taxon: oi=k=1mxkyko_i = \sum_{k = 1}^{m} x_k \cap y_k,
  • ojo_j denotes the number of type/taxon common to both sample/case: oj=k=1Sakbko_j = \sum_{k = 1}^{S} a_k \cap b_k.
## Brainerd-Robinson (similarity between assemblages)
BR <- similarity(mississippi, method = "brainerd")
plot_spot(BR, col = khroma::colour("YlOrBr")(12))


## Binomial co-occurrence (similarity between types)
BI <- similarity(mississippi, method = "binomial")
plot_spot(BI, col = khroma::colour("PRGn")(12))

References

Brainerd, G. W. 1951. The Place of Chronological Ordering in Archaeological Analysis. American Antiquity, 16(4), 301-313. DOI: 10.2307/276979.

Bray, J. R. & Curtis, J. T. (1957). An Ordination of the Upland Forest Communities of Southern Wisconsin. Ecological Monographs, 27(4), 325-349. DOI: 10.2307/1942268.

Cody, M. L. (1975). Towards a Theory of Continental Species Diversity: Bird Distributions Over Mediterranean Habitat Gradients. In M. L. Cody & J. M. Diamond (Eds.), Ecology and Evolution of Communities, 214-257. Cambridge, MA: Harvard University Press.

Kintigh, K. (2006). Ceramic Dating and Type Associations. In J. Hantman & R. Most (Eds.), Managing Archaeological Data: Essays in Honor of Sylvia W. Gaines, 17–26. Anthropological Research Paper 57. Tempe, AZ: Arizona State University. DOI: 10.6067/XCV8J38QSS.

Moreno, C. E. & Rodríguez, P. (2010). A Consistent Terminology for Quantifying Species Diversity? Oecologia, 163(2), 279-782. DOI: 10.1007/s00442-010-1591-7.

Robinson, W. S. (1951). A Method for Chronologically Ordering Archaeological Deposits. American Antiquity, 16(4), 293-301. DOI: 10.2307/276978.

Routledge, R. D. (1977). On Whittaker’s Components of Diversity. Ecology, 58(5), 1120-1127. DOI: 10.2307/1936932.

Whittaker, R. H. (1960). Vegetation of the Siskiyou Mountains, Oregon and California. Ecological Monographs, 30(3), 279-338. DOI: 10.2307/1943563..

Wilson, M. V. & Shmida, A. (1984). Measuring Beta Diversity with Presence-Absence Data. The Journal of Ecology, 72(3), 1055-1064. DOI: 10.2307/2259551.
